ASPEN WATER purification systems range in capacity from 3,800 to 38,000 liters (1,000 to 10,000 gallons) per day of highly purified water. The fresh water systems can draw water from lakes, rivers, ponds, ditches or standing water. All Aspen systems effectively remove chemical and/or biological contamination.

Power Sources. Aspen systems are capable of operating on either AC or DC power in ranges as varied as 90 to 260 volts AC at either 50 or 60 hertz as well as 10 to 30 volts DC; simply any electrical power source. The military versions are capable of operating from 24/28 volt DC taken from government vehicles. Power cords with military type quick-connects are also provided.

(Note: A Solar option package is also available.)

Two Stage Filtration. The first stage removes sand, dirt and very fine particles. The second stage removes harmful microorganisms such as Paramecium, Amoeba, Giardia, Cryptosporidium and other small matter down to 1 micron.

Water Treatment. Replaceable multi-media water treatment canisters effectively treat from 34,000 to 380,000 liters (9,000 to 100,000 gallons) of surface water containing contaminants such as mercury, lead, barium, selenium and arsenic, prior to replacement. They also remove high levels of manmade pollutants such as solvents and insecticides. When used to ensure microbial destruction on clear water, the canister can be used for up to twice the rated capacities.

Disinfecting. An ultraviolet (UV) exposure unit is included on all systems as the primary source of disinfection. They are rated from 7 to 60 liters (1.8 to over 15 gallons) per minute and provide as much as two times the safety factor required by the US regulatory agencies and exceeds the World Health Organization’s standards for total disinfection.

Safety Features. The operating and monitoring components are designed with a two-stage protective shutdown system. First, the overall system automatically shuts down in the event of a failure in the disinfecting process. Secondly, the pump stops and a valve closes, preventing any more water from passing through the system. The Model 10,000 has an override due to the chlorine system as a second form of disinfection.
